Middleware: Skill

Skill Middleware provides Skill support for Eino ADK Agents, enabling Agents to dynamically discover and use predefined skills to complete tasks more accurately and efficiently.

What is a Skill

A Skill is a folder containing instructions, scripts, and resources that Agents can discover and use on demand to extend their capabilities. The core of a Skill is a SKILL.md file containing metadata (at least name and description) and instructions guiding the Agent to perform specific tasks.

my-skill/
├── SKILL.md          # Required: Instructions + metadata
├── scripts/          # Optional: Executable code
├── references/       # Optional: Reference documentation
└── assets/           # Optional: Templates, resources

Skills use Progressive Disclosure to efficiently manage context:

  1. Discovery: At startup, the Agent only loads the name and description of each available Skill, enough to determine when the Skill might be needed
  2. Activation: When a task matches a Skill’s description, the Agent reads the complete SKILL.md content into context
  3. Execution: The Agent follows instructions to execute the task, and can also load other files or execute bundled code as needed. This approach keeps the Agent responsive while allowing on-demand access to more context.

💡 Ref: https://agentskills.io/home

Interface Introduction

FrontMatter

The metadata structure of a Skill, used for quick display of Skill information during discovery phase, avoiding loading full content:

type FrontMatter struct {
    Name        string      `yaml:"name"`
    Description string      `yaml:"description"`
    Context     ContextMode `yaml:"context"`
    Agent       string      `yaml:"agent"`
    Model       string      `yaml:"model"`
}
FieldTypeDescription
Name
string
Unique identifier for the Skill. Agent calls the Skill by this name. Recommend using short, meaningful names (e.g.,
pdf-processing
,
web-research
). Corresponds to the
name
field in SKILL.md frontmatter
Description
string
Description of Skill functionality. This is the key basis for Agent to decide whether to use the Skill, should clearly explain applicable scenarios and capabilities. Corresponds to the
description
field in SKILL.md frontmatter
Context
ContextMode
Context mode. Possible values:
fork
(copy history messages to create new Agent for execution),
isolate
(create new Agent with isolated context for execution). Leave empty for inline mode (directly return Skill content)
Agent
string
Specify the Agent name to use. Used with
Context
field, gets the corresponding Agent factory function via
AgentHub
. Leave empty to use default Agent
Model
string
Specify the model name to use. Gets the corresponding model instance via
ModelHub
. In Context mode, passed to Agent factory; in inline mode, switches the model used by subsequent ChatModel calls

ContextMode

const (
    ContextModeFork    ContextMode = "fork"    // Copy history messages
    ContextModeIsolate ContextMode = "isolate" // Isolate context
)
ModeDescription
Inline (default)Skill content is returned directly as tool result, processed by current Agent
ForkCreate new Agent, copy current conversation history, execute Skill task independently and return result
IsolateCreate new Agent with isolated context (only containing Skill content), execute independently and return result

Skill

Complete Skill structure, containing metadata and actual instruction content:

type Skill struct {
    FrontMatter
    Content       string
    BaseDirectory string
}
FieldTypeDescription
FrontMatter
FrontMatter
Embedded metadata structure, including
Name
,
Description
,
Context
,
Agent
,
Model
Content
string
Body content after frontmatter in SKILL.md file. Contains detailed instructions, workflows, examples, etc. Agent reads this content after activating Skill
BaseDirectory
string
Absolute path of Skill directory. Agent can use this path to access other resource files in the Skill directory (such as scripts, templates, reference docs, etc.)

Backend

Skill backend interface, defining how skills are retrieved. The Backend interface decouples skill storage from usage, providing the following benefits:

  • Flexible storage: Skills can be stored in local file system, database, remote service, cloud storage, etc.
  • Extensibility: Teams can implement custom Backends as needed, such as dynamically loading from Git repository, getting from config center, etc.
  • Test friendly: Can easily create Mock Backend for unit testing
type Backend interface {
    List(ctx context.Context) ([]FrontMatter, error)
    Get(ctx context.Context, name string) (Skill, error)
}
MethodDescription
List
List metadata of all available skills. Called at Agent startup to build skill tool descriptions, letting Agent know which skills are available
Get
Get complete skill content by name. Called when Agent decides to use a skill, returns complete Skill structure with detailed instructions

AgentHub and ModelHub

When Skills use Context mode (fork/isolate), AgentHub and ModelHub need to be configured:

// AgentFactory creates Agent instances
type AgentFactory func(ctx context.Context, m model.ToolCallingChatModel) (adk.Agent, error)

// AgentHub provides Agent factory functions
type AgentHub interface {
    Get(ctx context.Context, name string) (AgentFactory, error)
}

// ModelHub provides model instances
type ModelHub interface {
    Get(ctx context.Context, name string) (model.ToolCallingChatModel, error)
}

NewBackendFromFilesystem

Backend implementation based on filesystem.Backend interface, reads skills from specified directory:

type BackendFromFilesystemConfig struct {
    Backend filesystem.Backend
    BaseDir string
}

func NewBackendFromFilesystem(ctx context.Context, config *BackendFromFilesystemConfig) (Backend, error)
FieldTypeRequiredDescription
Backend
filesystem.Backend
YesFile system backend implementation for file operations
BaseDir
string
YesPath to skills root directory. Scans all first-level subdirectories under this directory, looking for directories containing
SKILL.md
files as skills

How it works:

  • Scans first-level subdirectories under BaseDir
  • Looks for SKILL.md file in each subdirectory
  • Parses YAML frontmatter to get metadata
  • Deeply nested SKILL.md files are ignored

filesystem.Backend Implementations

The filesystem.Backend interface has the following two implementations to choose from:

Local Backend (Local File System)

Implementation based on local file system, suitable for Unix/MacOS environments:

import "github.com/cloudwego/eino-ext/adk/backend/local"

type Config struct {
    ValidateCommand func(string) error // optional
}

func NewBackend(ctx context.Context, cfg *Config) (filesystem.Backend, error)
FieldTypeRequiredDescription
ValidateCommand
func(string) error
NoCommand validation function for security checks before command execution

Note: Only supports Unix/MacOS, does not support Windows.

Sandbox Backend (Sandbox Environment)

Implementation based on Volcengine AgentKit sandbox tool, suitable for scenarios requiring isolated execution environments:

import "github.com/cloudwego/eino-ext/adk/backend/agentkit"

type Config struct {
    AccessKeyID      string
    SecretAccessKey  string
    Region           Region  // Optional, default cn-beijing
    ToolID           string
    SessionID        string  // Provide at least one of SessionID or UserSessionID
    UserSessionID    string  // Provide at least one of SessionID or UserSessionID
    SessionTTL       int     // Optional, default 1800 seconds
    ExecutionTimeout int     // Optional
    HTTPClient       *http.Client // Optional
}

func NewSandboxToolBackend(config *Config) (filesystem.Backend, error)
FieldTypeRequiredDescription
AccessKeyID
string
YesVolcengine Access Key ID
SecretAccessKey
string
YesVolcengine Secret Access Key
Region
Region
NoRegion, supports
cn-beijing
(default) and
cn-shanghai
ToolID
string
YesSandbox Tool ID
SessionID
string
NoSession ID, provide at least one of SessionID or UserSessionID
UserSessionID
string
NoUser Session ID, provide at least one of SessionID or UserSessionID
SessionTTL
int
NoSession TTL (seconds), range 60-86400, default 1800
ExecutionTimeout
int
NoCode execution timeout (seconds)

For more information see: Volcengine AgentKit Documentation

LocalBackend Built-in local file system backend implementation, reads skills from specified directory:

type LocalBackendConfig struct {
    BaseDir string
}

func NewLocalBackend(config *LocalBackendConfig) (*LocalBackend, error)
FieldTypeRequiredDescription
BaseDir
string
YesPath to skills root directory. LocalBackend scans all subdirectories under this directory, looking for directories containing
SKILL.md
files as skills

How it works:

  • Scans first-level subdirectories under BaseDir
  • Looks for SKILL.md file in each subdirectory
  • Parses YAML frontmatter to get metadata

Initialization

Create Skill Middleware (recommend using NewChatModelAgentMiddleware):

func NewChatModelAgentMiddleware(ctx context.Context, config *Config) (adk.ChatModelAgentMiddleware, error)

Config is configured as:

type Config struct {
    // Backend skill backend implementation, required
    Backend Backend

    // SkillToolName skill tool name, default "skill"
    SkillToolName *string

    // AgentHub provides Agent factory functions for Context mode
    // Required when Skill uses "context: fork" or "context: isolate"
    AgentHub AgentHub

    // ModelHub provides model instances for Skills specifying models
    ModelHub ModelHub

    // CustomSystemPrompt custom system prompt
    CustomSystemPrompt SystemPromptFunc

    // CustomToolDescription custom tool description
    CustomToolDescription ToolDescriptionFunc
}
FieldTypeRequiredDefaultDescription
Backend
Backend
Yes
  • Skill backend implementation. Responsible for skill storage and retrieval, can use built-in
    LocalBackend
    or custom implementation
    SkillToolName
    *string
    No
    "skill"
    Skill tool name. Agent calls skill tool by this name. If your Agent already has a tool with the same name, you can customize the name through this field to avoid conflicts
    AgentHub
    AgentHub
    No
  • Provides Agent factory functions. Required when Skill uses
    context: fork
    or
    context: isolate
    ModelHub
    ModelHub
    No
  • Provides model instances. Used when Skill specifies the
    model
    field
    CustomSystemPrompt
    SystemPromptFunc
    NoBuilt-in promptCustom system prompt function
    CustomToolDescription
    ToolDescriptionFunc
    NoBuilt-in descriptionCustom tool description function

    Quick Start

    Taking loading pdf skill from local as an example, complete code at https://github.com/cloudwego/eino-examples/tree/alpha/08/adk/middlewares/skill.

    • Create skills directory in working directory:
    workdir/
    ├── skills/
       └── pdf/
            ├── scripts
               └── analyze.py
            └── SKILL.md
    └── other files

    • Create local filesystem backend, and create Skill middleware based on backend:
    import
        "github.com/cloudwego/eino/adk/middlewares/skill"
        "github.com/cloudwego/eino-ext/adk/backend/local"



    be, err := local.NewBackend(ctx, &local.Config{})
    if err != nil {
        log.Fatal(err)
    }

    wd, _ := os.Getwd()
    workDir := filepath.Join(wd, "adk", "middlewares", "skill", "workdir")
    skillBackend, err := skill.NewBackendFromFilesystem(ctx, &skill.BackendFromFilesystemConfig{
        Backend: be,
        BaseDir: skillsDir,
    })

    • Create local Filesystem Middleware based on backend, for agent to read skill other files and execute scripts:
    import (
        "github.com/cloudwego/eino/adk/middlewares/filesystem"
    )

    fsm, err := filesystem.NewMiddleware(ctx, &filesystem.Config{
        Backend:                          be,
        WithoutLargeToolResultOffloading: true,
    })

    • Create Agent and configure middlewares
    agent, err := adk.NewChatModelAgent(ctx, &adk.ChatModelAgentConfig{
        Name:        "LogAnalysisAgent",
        Description: "An agent that can analyze logs",
        Instruction: "You are a helpful assistant.",
        Model:       cm,
        Middlewares: []adk.ChatModelAgentMiddleware{fsm, skillMiddleware},
    })

    • Call Agent and observe results
    runner := adk.NewRunner(ctx, adk.RunnerConfig{
        Agent: agent,
    })

    input := fmt.Sprintf("Analyze the %s file", filepath.Join(workDir, "test.log"))
    log.Println("User: ", input)

    iterator := runner.Query(ctx, input)
    for {
        event, ok := iterator.Next()
        if !ok {
           break
        }
        if event.Err != nil {
           log.Printf("Error: %v\n", event.Err)
           break
        }

        prints.Event(event)
    }


    Agent output:

    name: LogAnalysisAgent
    path: [{LogAnalysisAgent}]
    tool name: skill
    arguments: {"skill":"log_analyzer"}

    name: LogAnalysisAgent
    path: [{LogAnalysisAgent}]
    tool response: Launching skill: log_analyzer
    Base directory for this skill: /Users/bytedance/go/src/github.com/cloudwego/eino-examples/adk/middlewares/skill/workdir/skills/log_analyzer
    # SKILL.md content

    name: LogAnalysisAgent
    path: [{LogAnalysisAgent}]
    tool name: execute
    arguments:  {"command": "python3 /Users/bytedance/go/src/github.com/cloudwego/eino-examples/adk/middlewares/skill/workdir/skills/log_analyzer/scripts/analyze.py /Users/bytedance/go/src/github.com/cloudwego/eino-examples/adk/middlewares/skill/workdir/test.log"}

    name: LogAnalysisAgent
    path: [{LogAnalysisAgent}]
    tool response: Analysis Result for /Users/bytedance/go/src/github.com/cloudwego/eino-examples/adk/middlewares/skill/workdir/test.log:
    Total Errors: 2
    Total Warnings: 1

    Error Details:
    Line 3: [2024-05-20 10:02:15] ERROR: Database connection failed.
    Line 5: [2024-05-20 10:03:05] ERROR: Connection timed out.

    Warning Details:
    Line 2: [2024-05-20 10:01:23] WARNING: High memory usage detected.


    name: LogAnalysisAgent
    path: [{LogAnalysisAgent}]
    answer: Here's the analysis result of the log file:

    ### Summary
    - **Total Errors**: 2
    - **Total Warnings**: 1

    ### Detailed Entries
    #### Errors:
    1. Line 3: [2024-05-20 10:02:15] ERROR: Database connection failed.
    2. Line5: [2024-05-2010:03:05] ERROR: Connection timed out.

    #### Warnings:
    1. Line2: [2024-05-2010:01:23] WARNING: High memory usage detected.

    The log file contains critical issues related to database connectivity and a warning about memory usage. Let me know if you need further analysis!


    Principles

    Skill middleware adds system prompt and skill tool to Agent, system prompt content is as follows, {tool_name} is the tool name of skill tool:

    # Skills System

    **How to Use Skills (Progressive Disclosure):**

    Skills follow a **progressive disclosure** pattern - you see their name and description above, but only read full instructions when needed:

    1. **Recognize when a skill applies**: Check if the user's task matches a skill's description
    2. **Read the skill's full instructions**: Use the '{tool_name}' tool to load skill
    3. **Follow the skill's instructions**: tool result contains step-by-step workflows, best practices, and examples
    4. **Access supporting files**: Skills may include helper scripts, configs, or reference docs - use absolute paths

    **When to Use Skills:**
    - User's request matches a skill's domain (e.g., "research X" -> web-research skill)
    - You need specialized knowledge or structured workflows
    - A skill provides proven patterns for complex tasks

    **Executing Skill Scripts:**
    Skills may contain Python scripts or other executable files. Always use absolute paths.

    **Example Workflow:**

    User: "Can you research the latest developments in quantum computing?"

    1. Check available skills -> See "web-research" skill
    2. Call '{tool_name}' tool to read the full skill instructions
    3. Follow the skill's research workflow (search -> organize -> synthesize)
    4. Use any helper scripts with absolute paths

    Remember: Skills make you more capable and consistent. When in doubt, check if a skill exists for the task!


    Skill tool receives the skill name to load, returns the complete content in the corresponding SKILL.md, and informs agent of all available skill names and descriptions in the tool description:

    Execute a skill within the main conversation

    <skills_instructions>
    When users ask you to perform tasks, check if any of the available skills below can help complete the task more effectively. Skills provide specialized capabilities and domain knowledge.

    How to invoke:
    - Use this tool with the skill name only (no arguments)
    - Examples:
      - `skill: pdf` - invoke the pdf skill
      - `skill: xlsx` - invoke the xlsx skill
      - `skill: ms-office-suite:pdf` - invoke using fully qualified name

    Important:
    - When a skill is relevant, you must invoke this tool IMMEDIATELY as your first action
    - NEVER just announce or mention a skill in your text response without actually calling this tool
    - This is a BLOCKING REQUIREMENT: invoke the relevant Skill tool BEFORE generating any other response about the task
    - Only use skills listed in <available_skills> below
    - Do not invoke a skill that is already running
    - Do not use this tool for built-in CLI commands (like /help, /clear, etc.)
    </skills_instructions>

    <available_skills>
    {{- range .Matters }}
    <skill>
    <name>
    {{ .Name }}
    </name>
    <description>
    {{ .Description }}
    </description>
    </skill>
    {{- end }}
    </available_skills>


    Execution example:

    💡 Skill Middleware only provides the ability to load SKILL.md as shown above. If the Skill itself needs to read files, execute scripts, etc., users need to configure the corresponding capabilities for the agent separately.
